- Size: 4.58*1.92*1.7
- Place of Origin: Shandong
- Brand Name: Remax
- Model Number: 40120
- Weight: 1850.000 kg
- :
- :
- :
- :
- :
- :
gantry plasma cutting machine 4000*12000mm
Features:
1.All-welded structure, Y,X axis with rack and linear guide drive,Z axis with electric
automatic lifting,to assure cutting speed and quality.
2.Dual drive , stable performance .
3.The set-up is very simple, all kinds of CAD graphics can be read directly by our
system trough U-disk. The software can be edict graphics automatically.
4. CNC flame and plasma cutting Collocated U-disk interface and cutting code auto
converting software for CAD drawing ,CAD drawing can be input directly into the cutter
through U-disk.
Our service:
A Guarantee :
1.Two years warranty for the whole machine.
2.Within 2 years under normal use and maintenance,
3.If something is wrong with machine, you will get spare part for free.;
4.Out of 2 years, you will get spare part at cost price.
5.You will also get technical support and service all the lifetime.
B After sales services:
1.Normal machine is properly adjusted before dispatch.
2.You will be able to use the machines immediately.
3.You will be able to get free training advice towards our machine in our factory.
4.You will also get free suggestion and consulting, technical support and service by
email/fax/tel and lifetime technical support.
- Size: 4.58*1.92*1.7
- Place of Origin: Shandong
- Brand Name: Remax
- Model Number: 40120
- Weight: 1850.000 kg
- :
- :
- :
- :
- :
- :
Parameter:
Model | Remax-40120 | ||
Effective Cutting Width (X axis) | 3500mm | ||
Effective Cutting Length (Y axis) | 10000mm | ||
Plasma power | Jiusheng 400A | ||
Drive Mode | Bilateral-side | ||
CNC system | Beijing START CNC | ||
Plasma cutting speed | 50-6500 mm/min | ||
Cutting torch lifting distance | 150mm | ||
Speed setting error | ≤±5% | ||
Max Idle running speed | 12000mm/min | ||
Torch height controller accuracy | ≤±1.0mm | ||
Longitudinal line accuracy | ±0.2mm/10m | ||
Motor and driver | stepper motor and driver | ||
Gearbox | Hubei planet | ||
Drive Method | Rack and square rails for X Y Z axis | ||
Moving Precision | 0.01mm per step | ||
Power Source | 380V 50/60Hz | ||
Height controller(plasma) | HYD THC | ||
Plasma cutting thickness | 1-15mm | ||
length of a side | ±0.5mm | ||
Diagonal error |AD-BC| | ±0.5mm | ||
Base point return error | ±0.2mm | ||
Intersection point error | ±0.5mm | ||
Lineation forward- reverse error
| ±0.2mm | ||
